Viqua VH410-F20 Two Stage Whole House Purification System with 18 GPM UV Sterilizer

SKU:
VH410-F20
Condition:
New
Weight:
32.00 LBS
Shipping:
Calculated at Checkout
  • Viqua VH410-F20 Two Stage Whole House Purification System with 18 GPM UV Sterilizer
  • Viqua VH410-F20 Two Stage Whole House Purification System with 18 GPM UV Sterilizer
1,272.16CAD

Description

PRODUCT DOCUMENTATION

 Viqua Integrated Water Purification System combines 5 micron sediment and 18 GPM UV. This extremely compact water filtration system is a perfect choice for home or cottage application with a water flow above 10 GPM.

FEATURES & BENEFITS

  • Designed to destroy Bacteria, Viruses and inactivate chlorine-resistant parasites such as Cryptosporidium and Giardia
  • Stainless steel chamber to prolong UV intensity and eliminate ultraviolet light degradation
  • Easy to maintain and service
  • The BA-ICE-CL power supply visually displays the remaining lamp life
  • UV lamp can be changed without interrupting the water flow
  • 5 Micron sediment filter
  • Viqua VH410 UV system
  • Reversible, heavy duty bracket

SPECIFICATION

  • Part Number: VH410-F20
  • Desinfection Flow Rate: 30 mJ/cm2 @ 18.0 gpm
  • Desinfection Flow Rate: 40 mJ/cm2 @ 14.0 gpm
  • The UV Lamp Life: 9000 hours of continuous purification
  • Connection Size: 3/4"-1"MNPT Combo
  • Power Consumption: 60W
  • Voltage: 100-240V/50/60 Hz
  • Maximum Operating Pressure: 125 PSI

REPLACEMENT PARTS

  • Replacement UV Lamp: S410RL-HO
  • Replacement UV Sleeve: QSO-410
  • Replacement Lamp & Combo Kit: QL-410
  • Replacement Power Supply: BA-ICE-CL
  • Replacement O-Ring: 410867
  • Retaining Nut: RN-001
  • Filter Housing: AWP42B-V
  • 5 Micron Sediment Cartridge: CMB-520-HF

WATER QUALITY REQUIREMENTS PRIOR TO UV TREATMENT

  • Iron < 0.3 ppm (0.3 mg/L)
  • Manganese < 0.05 ppm (0.05 mg/L)
  • Hardness < 7gpg
  • Tannins < 0.1 ppm (0.1 mg/L)
  • Turbidity < 1NTU UV transmittance > 75%
